TECHNICAL FEATURES

• AVERAGE PRODUCTION OUTPUT: depending on the type of gummed paper used 6/7 carton/min with paper with vegetable glue 12/14 carton/min with animal glue paper THE MACHINE CONSISTS OF TWO STATIONS: 1st station: DCM
• Pneumatic carton centring device for the insertion of the cartons in line with the taping heads
• Carton height detection device by means of a feeler for positioning the upper taping unit-holder carriage
• 2 pneumatic carton stop blades
• Roller diameter 50 mm, centre distance 75 mm
• Motorisation by means of rollers
• Adjustable roller speed 2nd station – closing of upper flaps and upper and lower carton taping
• Automatic top flap closing
• Automatic adjustment to various carton formats in width, height and length
• Self-sizing in width and height
• Lifting and lowering of upper taping unit carriage with Brushless motor
• Self-sizing in width with pneumatic drive
• Automatic and simultaneous top and bottom taping
• Upper and lower taping head with rubberised paper capable of using normal, watermarked or heavy reinforced papers
• Adjustable tape width mm 50-80 W x mm 40-80 overlap
• Paper humidification heating by means of 50W stainless steel cartridge heating element
• Pneumatically controlled, self-adjusting and self-sharpening cutting units
• Pneumatic pressing side rollers kit
• Switchboard with Siemens S7 1200 PLC
• Kite colour control panel mod. P07 7″ with self-diagnostics
• Power supply: 400V 3Ph + N + T 50 Hertz, 24 V
• Installed power: 1 kW
• Electrical protection: IP 54
• Operating temperature: + 0° C -max. + 40° C
• Pneumatics: FESTO
• Pneumatic working pressure: 6 bar
• Air consumption per cycle: 5 Nl/cycle
• RAL fixed parts 7004, moving parts 6029
• Worktable height: 650 mm
• Safety guards to CE standards
